The power rating of this engine is the net power tested on a production engine for this engine model and measured in accordance with SAE J1349 at a specified rpm. The power rating of this engine is the net power tested on a production engine for this engine model and measured in accordance with SAE J1349 at a specified rpm.
OHV design enhances combustion efficiency
High power-to-displacement ratio
Easy starting with an automatic decompression system and an easy-to-grip soft recoil starter handle
High quality materials and purpose-built components which ensure reliable, long-term use
Meets world's most stringent environmental legislation
Low fuel and oil consumption
Reduced vibration and noise levels
| Engine type: | 4-stroke single cylinder, OHV petrol engine, 25° inclined cylinder, Horizontal shaft |
| Cylinder sleeve type: | Cast iron sleeve |
| Bore x Stroke: | 68 x 45 mm |
| Displacement: | 163 cm?3; |
| Compression ratio: | 9.0 : 1 |
| Net power: | 3.6 kW ( 4.8 HP ) / 3600 rpm |
| Cont rated power: | 2.5 kW ( 3.4 HP ) / 3000 rpm, 2.9 kW ( 3.9 HP ) / 3600 rpm |
| Max. net torque: | 10.3 Nm / 1.05 kgfm / 2500 rpm |
| Ignition System: | Transistorised |
| Starter: | Recoil (el. start optional) |
| Fuel tank capacity: | 3.1 Liter |
| Fuel cons. at cont. rated power: | 1.4 L/h - 3600 rpm |
| Engine oil capacity: | 0.6 Liter |
| Dimensions (L x W x H): | 312 x 362 x 346 mm |
| Dry weight: | 15.1 kg |
